Specification | Value |
---|---|
Supplier Package | DIP-14 |
Pin Count | 14 |
Features
- Operating Voltage: 2 ~ 6 V
- Package: 14 Pin DIP
- Low power dissipation
- High noise immunity
- Is Discontinued By Manufacturer ๐No
- Product Dimensions ๐1.5 x 1.5 x 0.5 cm; 50 Grams
- Date First Available ๐7 January 2017
- Manufacturer ๐INVENTO
- ASIN ๐B081RWHJQZ
- Item model number ๐ISC 1785
- Country of Origin ๐India
- Manufacturer ๐INVENTO, No
- Item Weight ๐50 g
- Item Dimensions LxWxH ๐15 x 15 x 5 Millimeters
- Generic Name ๐INVENTO 5Pcs SN74HC05N 7405 IC Inverter, 74HC05, 1 Input, 25 mA, 2 V to 6 V, DIP-14
- Package Include 5 x 7405 IC. The SN74HC05N is a 1-input 14-pin Hex Inverter made of CU NIPDAU lead/ball finish. The device contains six independent inverters. It performs the Boolean function Y = A in positive logic. The open-drain outputs require pull-up resistors to perform correctly. It may be connected to other open-drain outputs to implement active-low wired-OR or active-high wired-AND functions. Logic Family / Base Number: 74HC05; Logic Type: Inverter; Output Current: 25mA; No. of Inputs: 1 Supply Voltage Min: 2V; Supply Voltage Max: 6V; No. of Pins: 14Pins; Logic IC Base Number: 7405
