LC1D12MD SCHNEIDER CONTACTOR

LC1D12MD Schneider Electric Contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3/3e (5.5kW@400V). It provides a 220V DC coil with transient suppressor module, 1NO+1NC built-in auxiliary contacts, connection by screw clamp terminal, LC1D12MD Schneider Contactor.

Specifications
  • Brand : Schneider
  • Model : LC1D12MD
  • Product type : Contactor
  • Auxiliary Contact Configuration : 1NO + 1NC
  • Normal State : 3NO
  • Number of Auxiliary Contacts : 2
  • Coil Voltage : 230VDC
  • Current Rating :  12A
  • Number of poles : 3
  • Mounting Style  :DIN Rail
  • Switch Type : Alternating Current
  • Contact Voltage Rating : 690 V ac /dc
  • Terminal Style : Screw Clamp
  • Circuit Frequency : 25…400 Hz
  • Minimum Switching Contact  : 17V 5mA
  • Operating Temperature : -40…+60 °C
  • Dimension : 95 x 45 x 77 mm
  • Weight : 490g
